amphibious excavator
Dredging Swamp Buggy Marsh Amphibious Excavator with Undercarriage Floating Pontoon and Long Arm Reach for Wetland/River/PondAmphibious excavators are multi-purpose excavators used in land, shallow water, marsh and deep water areas. After years of practical testing, Relong amphibious excavator has been recognized and trusted by the majority of users. The upper half structure can choose the excavator brand and all kinds of machine you need. Various types of buoyancy tank have been designed and widely used, which can be adapted to 5-40 ton excavator, and can also be customized according to your working conditions and requirements, in accordance with your exclusive scheme.
Main feature
1. Wide applicability. Can be used for cutter suction, digging, grabbing, piling, weeding, barrier cleaning etc. in water area of closed, narrow, shallow, heavily polluted etc..
2. Strong mobility. No need for crane, can go in and out of the water area easily; Self-propulsion with propellers; stable with spuds and support legs.
3. High automation. Workers with excavator operation skills can operate easily after a little training.
4. Good economics. Using of submersible mud pump cutter compound equipment ensures the slurry density high; Comparing with cabin mud pump, the oil consumption is reduced obviously.
FAQ
1.Where has your plant export to ?
Africa: Sudan,Ghana,Mali,etc...
East South Asia :Burma,Philippines,Indonesia,etc...
LatinAmerica:Surinam,Chile
Others:Papua New Guinea
2.What's your main products ?
We focus alluvial gold mining equipment and cutter suction /chain bucket/j et suction dredger .Kindly contact us for catalog,please
3.What's your warranty ?
We have ISO cetification and provide 1year warranty for all of our products.Allspare parts will be provided fast and cheap for ever.
4.Do you also design plant ?
Yes.Although we have some popular models.but the real good palnt is designed for clients,based on the condition of gold mine site
|
Model 35
|
35
|
|
Dimensions
|
7.5x2.25x3.2m
|
|
Travel speed
|
2-4kw/h
|
|
Maximumgroundclearance
|
0.7m
|
|
Bucket capacity
|
0.1m3
|
|
Ratedpower
|
37kw/2400rpm
|
|
Bucket digging force
|
30KN
|
|
Maximumdiggingradius
|
5.4m
|
|
Maximumdiggingheight
|
4.8m
|
|
Maximum digging depth
|
3m
|
|
Floats
|
|
|
Dimensions
|
4.5x0.8x1m
|
|
Materials
|
4mm steelplate
|
|
Quantity
|
2pcs
|
|
Hydraulic motor
|
|
|
Brand
|
Eddie
|
|
Model
|
STM02
|
|
Rated pressure
|
30
|
|
Quantity
|
2pcs
|
|
Chain
|
|
|
Pitch
|
125mm
|
|
Quantity
|
2articles
|
|
Spacing
|
450
|
|
Quantity
|
2sets
|
|
Side Floats
|
|
|
Dimensions
|
3*0.75*0.75
|
|
Materials
|
3mm steelplate
|
|
Quantity
|
2pcs
|
|
Positioningstake
|
12-footpipe
|
